| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CIF,EXW |
| Min. Order: | 30 Set/Sets |
| Transportation: | Ocean |
| Port: | Qingdao,Shanghai,Ningbo |
Main feature:
1. wholly new designed outer appearance, which makes the engine more beautiful.
2.Large capacity fuel tank, which makes the engine works longer.
3.Single balance , the engines works more stable.
4.The specific fuel is low, the engine works more economically.
5.Excellent start ability, easy to start.
6.Oil bath air-filter makes the engine more suitable to the bad circumstances.
It is a popular matched type at present: as a power device used for mini-tractor, transportation vehicle in agricultural.
Main application: Small generating sets, air-compressor, inland ships, engineering machinery and processing machines for agricultural products and sideline products(e.g. thresher, rice mill, flouring mill machine, fodder grinder.)
|
Model |
ZS195 |
ZS1100 |
ZS1105 |
ZS1110 |
ZS1115 |
|
Type |
Single cylinder, horizontal, 4 stroke water cool |
||||
|
Combustion System |
Direct injection |
Direct injection |
Direct injection |
Direct injection |
Direct injection |
|
Bore*Stroke(mm) |
95115 |
100115 |
105115 |
110115 |
115115 |
|
Total Displacement(L) |
0.815 |
0.903 |
0.996 |
1.093 |
1.194 |
|
Rated output(kw/rpm) |
8.82 |
11.03 |
12.1 |
13.24 |
14.7 |
|
Max output(kw/rpm) |
9.7 |
12.13 |
13.31 |
14.56 |
16.17 |
|
Rated speed(r/min) |
2000 |
2200 |
2200 |
2200 |
2200 |
|
Specific Fuel(g/kw*h) |
≤244.8 |
≤246.2 |
≤246.2 |
≤244.8 |
≤244.8 |
|
Cooling system consumption |
Evaporative |
Evaporative |
Evaporative |
Evaporative |
Evaporative |
|
Lubrication method |
Pressure/Splash |
Pressure/Splash |
Pressure/Splash |
Pressure/Splash |
Pressure/Splash |
|
Starting method |
Hand cranking /Electric cranking |
Hand cranking /Electric cranking |
Hand cranking /Electric cranking |
Hand cranking /Electric cranking |
Hand cranking /Electric cranking |
|
Net weight(kg) |
148 |
153 |
155 |
180 |
183 |
| Selling Units | : | Set/Sets |
| Package Type | : | Wooden box packing |
